140CPU65260 Specifications
| Manufacturer: | Modicon Quantum |
| Series: | Quantum CPUs |
| Weight: | 3 lb |
| Product or component type: | Unity processor |
| Clock frequency: | 266 MHz |
| Number of slots: | 10 |
| 16 | |
| 2 | |
| 4 | |
| 6 | |
| Number of racks: | 2 – local rack(s) |
| Number of distributed I/O station: | 63 station(s) – 1 rack(s) – 1 Modbus Plus network(s) |
140CPU65260 – Unity processor Modicon Quantum
| RANGE OF PRODUCT |
Modicon Quantum automation platform
|
|
|---|---|---|
| PRODUCT OR COMPONENT TYPE |
Unity processor
|
| CLOCK FREQUENCY |
266 MHz
|
|
|---|---|---|
| NUMBER OF SLOTS |
6
4 2 16 10 |
|
| NUMBER OF RACKS |
2 – local rack(s)
|
|
| NUMBER OF DISTRIBUTED I/O STATION |
63 station(s) – 1 rack(s) – 1 Modbus Plus network(s)
|
|
| NUMBER OF REMOTE I/O STATION |
31 – 2 S908 remote I/O rack(s)
31 – 2 ethernet Quantum remote I/O rack(s) 31 – 2 ethernet X80 remote I/O rack(s) |
|
| DISCRETE I/O NUMBER |
Unlimited (31 drops of 28 slots max) – ethernet remote I/O
31744 inputs, 31744 outputs – S908 remote I/O 8000 inputs, 8000 outputs – distributed – per network Modbus Plus Unlimited (26 slots max) – local |
|
| ANALOGUE I/O NUMBER |
Unlimited (26 slots max) – local
Unlimited (31 drops of 28 slots max) – ethernet remote I/O 500 inputs, 500 outputs – distributed – per network Modbus Plus 1984 inputs,1984 outputs – remote |
|
| APPLICATION SPECIFIC I/O |
Serial link
Accurate time stamping High-speed interrupt inputs Counter |
|
| COMMUNICATION SERVICE |
Ethernet router
|
|
| NUMBER OF OPTIONAL MODULES |
6 ( Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
|
|
| MAXIMUM NUMBER OF CONNECTIONS |
1 ( USB)
2 ( AS-Interface) – distributed 4 ( AS-Interface) – remote 6 ( Ethernet TCP/IP) – local 6 ( Modbus Plus) – local 6 ( Profibus DP) – local 1 ( Modbus) – RS232/485 Modbus/ASCII |
|
| INTEGRATED CONNECTION TYPE |
1 Modbus Plus with
1 Ethernet TCP/IP with 1 Modbus with 1 USB with |
|
| CHECKS |
Process control
|
|
| MEMORY DESCRIPTION |
Expandable 7168 kB – program with PCMCIA card
Expandable 8 MB – file storage with PCMCIA card Internal RAM 3072 kB |
|
| SWITCH FUNCTION |
Key switch memory port on/off
|
|
| APPLICATION STRUCTURE |
1 cyclic/periodic master task –
1 periodic fast task – 128 I/O interrupt tasks – 128 interrupt tasks – 32 timer interrupt tasks – 4 auxiliary tasks – |
|
| NUMBER OF INSTRUCTIONS PER MS |
10.28 Kinst/ms if 100 % Boolean
10.07 Kinst/ms if 65 % Boolean and 35 % numerical |
|
| SYSTEM OVERHEAD |
1 ms – master task
0.2 ms – fast task |
|
| BUS CURRENT REQUIREMENT |
2760 mA
|
|
| LOCAL SIGNALLING |
1 LED green Ethernet activity (COM)
1 LED red Ethernet collision |
|
| ELECTRICAL CONNECTION |
1 connector, connector type: RJ45 for connecting Ethernet network
1 connector, connector type: RJ45 for connecting Modbus bus 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network |
