6ES7660-7GA10-3BB1
SIMATIC PCS 7 Industrial Workstation IPC547G (rack PC, 19″, 4 U), interfaces: 2x Gbit Ethernet (RJ45); 1x DVI-D; 2x Display Port V1.2 1x COM; 2x PS/2; audio; 2x USB 3.0 on the front, 4x USB 3.0 & 4x USB 2.0 on the rear side; 1x USB 2.0 internal; 7 slots: 5X PCI Express, 2x PCI; temperature and fan monitoring, watchdog, card retainer; Xeon E3-1275v5 (4C/8T, 3.6(4.0) GHz, 8 MB cache); MB (chipset C236) – ES/OS Single Station 1×1 TB HDD, internal (0.2g vibration, 1g shock); 8 GB DDR4 SDRAM (2 x 4 GB), Dual Channel; BCE PCS 7 V9.0 SP3 pre-installed Windows 10 IoT Enterprise 2015 LTSB, 64 bit, MUI (en, de, fr, it, es, cn) Enclosure blue chromated, without optical drive, 4-screen multi-monitor (combined, onboard interfaces (2 x DP) + Dual Head PCIE X16 board (2 x DP)), incl. 1XDP to DVI-D adapter cable, incl. 1xDual DVI-I adapter for Dual Head PCIE X16 board 100/240V AC industrial power supply unit; Power supply cable Europe
Product | |
Article Number (Market Facing Number) | 6ES7660-7GA10-3BB1 |
Product Description | SIMATIC PCS 7 Industrial Workstation IPC547G (rack PC, 19″, 4 U), interfaces: 2x Gbit Ethernet (RJ45); 1x DVI-D; 2x Display Port V1.2 1x COM; 2x PS/2; audio; 2x USB 3.0 on the front, 4x USB 3.0 & 4x USB 2.0 on the rear side; 1x USB 2.0 internal; 7 slots: 5X PCI Express, 2x PCI; temperature and fan monitoring, watchdog, card retainer; Xeon E3-1275v5 (4C/8T, 3.6(4.0) GHz, 8 MB cache); MB (chipset C236) – ES/OS Single Station 1×1 TB HDD, internal (0.2g vibration, 1g shock); 8 GB DDR4 SDRAM (2 x 4 GB), Dual Channel; BCE PCS 7 V9.0 SP3 pre-installed Windows 10 IoT Enterprise 2015 LTSB, 64 bit, MUI (en, de, fr, it, es, cn) Enclosure blue chromated, without optical drive, 4-screen multi-monitor (combined, onboard interfaces (2 x DP) + Dual Head PCIE X16 board (2 x DP)), incl. 1XDP to DVI-D adapter cable, incl. 1xDual DVI-I adapter for Dual Head PCIE X16 board 100/240V AC industrial power supply unit; Power supply cable Europe |
Series name | SIMATIC PCS 7 |
Industrial Workstation IPC547G | |
rack PC | |
Size | 19″ |
Processor type/CPU | Xeon E3-1275v5 |
Memory capacity | 8 GB DDR4 SDRAM |
Dual channel | |
Operating system/OS | Windows 10 IoT Enterprise 2015 LTSB, 64 bit, MUI |
Network Interface | 2x Gbit Ethernet (RJ45) |
Other interface | 1x DVI-D; 2x Display Port V1.2 1x COM; 2x PS/2; audio; 2x USB 3.0 on the front, 4x USB 3.0 & 4x USB 2.0 on the rear side; 1x USB 2.0 internal; 7 slots: 5X PCI Express, 2x PCI |
Power supply | 100/240V AC |
Warranty | 1 year |
Net Weight (kg) | 15.000 Kg |
Packaging Dimension | Not available |
Country of origin | Germany |
Quantity Unit | 1 Piece |
Packaging Quantity | 1 |
Additional Product Information | |
EAN | Not available |
UPC | Not available |
Commodity Code | 84715000 |
LKZ_FDB/ CatalogID | STPCS7 |
Product Group | 4519 |
Group Code | R1TP |
