7SJ6812-5EW20-3FE0
MULTIFUNCTION PROTECTIVE RELAY CASE 1/3 19″, 8BI, 8BO, 1 LIVE-STATUS CONTACT PHASE CURRENT TRANSFORMER 1A, SENSITIVE EARTH CURRENT TRANSF. SUPPLY VOLTAGE:DC 110V TO 250V, AC 115V TO 230V, BINARY INPUT THRESHOLD 88V DC FLUSH MOUNTING CASE, SCREW TYPE TERMINALS (RING TYPE CABLE LUG CONNECT.) REGION CHINA, 50HZ, IEC/ANSI, LANGUAGE CHINESE (LANGUAGE FIXED) SYSTEM INTERFACE (PORT B) IEC 60870-5-103 PROTOCOL, RS485 WITH FRONT PORT, NO PORT C WITH CONTROL, WITH USER-PREDIFINED OBJECTS FUNCTIONALITY: PHASE OVERCURRENT (50/51): I>,I>>,IP,REVERSE INTERLOCKING, INDEPENDENT OF PHASE ROTATION, EARTH-FAULT PROTECTION(50N/51N) IE>,IE>>,IEP, INRUSH BLOCKING, DIR. EARTH FIT. PROTECTION (SENSITIVE OR NON-SENSITIVE): IEE>, IEE>>,IEEP 67N(S)/50N(S)/51N(S), UNDERCURRENT MONITORING (37), NEGATIVE SEQUENCE PROTECT.(46), PHASE SEQUENCE MONITORING (47), DISPLACEMENT VOLTAGE (64/59N), UNDER-/OVERVOLTAGE (27/59), UNDER-/OVERFREQUENCY (81U/O) FLEXIBLE PROTECT.FUNCTIONS(81R) TRIP CIRCUIT SUPERVISION (74TC) 4 SETTING GROUPS, COLD LOAD PICKUP, LOCK OUT (86) WITHOUT AUTO-RECLOSURE
| Product | |
| Article Number (Market Facing Number) | 7SJ6812-5EW20-3FE0 |
| Product Description | MULTIFUNCTION PROTECTIVE RELAY CASE 1/3 19″, 8BI, 8BO, 1 LIVE-STATUS CONTACT PHASE CURRENT TRANSFORMER 1A, SENSITIVE EARTH CURRENT TRANSF. SUPPLY VOLTAGE:DC 110V TO 250V, AC 115V TO 230V, BINARY INPUT THRESHOLD 88V DC FLUSH MOUNTING CASE, SCREW TYPE TERMINALS (RING TYPE CABLE LUG CONNECT.) REGION CHINA, 50HZ, IEC/ANSI, LANGUAGE CHINESE (LANGUAGE FIXED) SYSTEM INTERFACE (PORT B) IEC 60870-5-103 PROTOCOL, RS485 WITH FRONT PORT, NO PORT C WITH CONTROL, WITH USER-PREDIFINED OBJECTS FUNCTIONALITY: PHASE OVERCURRENT (50/51): I>,I>>,IP,REVERSE INTERLOCKING, INDEPENDENT OF PHASE ROTATION, EARTH-FAULT PROTECTION(50N/51N) IE>,IE>>,IEP, INRUSH BLOCKING, DIR. EARTH FIT. PROTECTION (SENSITIVE OR NON-SENSITIVE): IEE>, IEE>>,IEEP 67N(S)/50N(S)/51N(S), UNDERCURRENT MONITORING (37), NEGATIVE SEQUENCE PROTECT.(46), PHASE SEQUENCE MONITORING (47), DISPLACEMENT VOLTAGE (64/59N), UNDER-/OVERVOLTAGE (27/59), UNDER-/OVERFREQUENCY (81U/O) FLEXIBLE PROTECT.FUNCTIONS(81R) TRIP CIRCUIT SUPERVISION (74TC) 4 SETTING GROUPS, COLD LOAD PICKUP, LOCK OUT (86) WITHOUT AUTO-RECLOSURE |
| Product family | PROTECTION RELAY |
| 1/3 19″ | |
| Power voltage | DC 110V TO 250V |
| AC 115V TO 230V | |
| CURRENT | 1A |
| Warranty | 1 Year |
| Net Weight (kg) | Not available |
| Packaging Dimension | Not available |
| Country of origin | China |
| Quantity Unit | 1 Piece |
