6SL3225-0BH27-5UA1
Image similar
SINAMICS G120 Power Module PM260 unfiltered capable of energy recovery 500-690 V 3 AC +10/-10% 47-63 Hz power high overload: 7.5 kW at 200% 3 s, 150% 57 s, 100% 240 s; ambient temperature -10 to +50 °C power low overload: 11 kW at 140% 3 s, 110% 57 s, 100% 240 s; ambient temperature -10 to +40 °C 512x 275x 204 (HxWxD), FSD degree of protection IP20 without Control Unit and BOP
| Product | |
| Article Number (Market Facing Number) | 6SL3225-0BH27-5UA1 |
| Product Description | SINAMICS G120 Power Module PM260 unfiltered capable of energy recovery 500-690 V 3 AC +10/-10% 47-63 Hz power high overload: 7.5 kW at 200% 3 s, 150% 57 s, 100% 240 s; ambient temperature -10 to +50 °C power low overload: 11 kW at 140% 3 s, 110% 57 s, 100% 240 s; ambient temperature -10 to +40 °C 512x 275x 204 (HxWxD), FSD degree of protection IP20 without Control Unit and BOP |
| Product family | SINAMICS G120 |
| Power Module PM260 | |
| Input Voltage（V）电压 | 500-690 V 3 AC |
| temperature | -10 to +50 °C |
| Power（KW/HP) | 7.5 kW-11 kW |
| Frequency（HZ）频率 | 47-63 Hz |
| degree of protection | IP20 |
| Warranty | 1 YEAR |
| Net Weight (kg) | 23,700 Kg |
| Packaging Dimension | 378,00MM x 589,00MM x 290,00MM |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | 4019169457712 |
| UPC | 40892585117 |
| Commodity Code | 85044085 |
| LKZ_FDB/ CatalogID | D11.1SD |
| Product Group | 9486 |
| Group Code | R2S3 |
